There are good reasons the Mattoc is the performance benchmark for MTB riders worldwide: Unparalleled adjustability, supreme dampening performance, and Manitou’s renowned reliability. We’ve upgraded that winning formula to include low-friction dust seals that improve bump sensitivity, and IRT air spring adjustability that creates a plush beginning stroke with excellent mid-stroke support. And, a Comp-level Performance package brings Mattoc performance to even more riders.
KEY FUTURES:
- 100mm (adjustable 80-100mm); 120mm (adjustable 120-140mm); 160mm (adjustable 140-160mm) Travel
- 44mm (27.5"); 48mm (27.5+/29"); 51mm (29+) Offset
- Expert Air Spring
- VTT Compression Damping
- Adjustable TPC Rebound Damping
SPECIFICATIONS:
- Wheel Size: 27.5" 27.5" Boost 27.5+/29" 29+
- Weight: 1996g (27.5") 2072g (27.5" Boost) 2222g (27.5+/29") 2245g (29+)
- Offset: 44mm (27.5", 27.5" Boost) 51mm (27.5+/29", 29+)
- Ride Height: 529-549mm (27.5") 535-565mm (27.5" Boost) 509-549mm (27.5+/29") 511-551mm (29+)
- Travel: 140-160mm (27.5") 140-170mm (27.5" Boost) 100-140mm (27.5+/29") 80-120mm (29+) (Internally adjustable in 10mm increments)
- Spring: Expert Air w/ IVA
- Compression Damping: VTT
- Rebound Damping: Adjustable TPC Cartridge
- Adjustments: Air Pressure, Air Volume, Rebound, 3-position Compression (Open, Trail, Lock)
- Steerer: 1.5" Tapered
- Crown: Forged Aluminum, Hollow
- Leg Diameter: 34mm
- Leg Material: 6000 Series straight wall Aluminum
- Brake: Post Mount 180mm (203mm Max)
- Axle: 15mm x 100mm Hexlock SL (27.5") 15mm x 110mm Hexlock SL (27.5" Boost, 27.5+/29", 29+)
- Max Tire Size: 63mm (27.5") 67mm (27.5" Boost) 87mm (27.5+), 65mm (29") 87mm (29+)
- E-Pac: Yes (27.5") Yes up to 160mm (27.5" Boost) Yes (27.5+/29") No (29+)
